| Specifications |
|
| Item | Model: RST504 |
| Complete Engine | 4-cylinder, mechanical in-line (National) Stage II emission control engine |
| Type | (Same as above) |
| Rated Power | 36.8 kW |
| Rated Speed | 2400 rpm |
| Transmission | (No description) |
| Clutch | Dryer, 12R |
| Gear Shift | 12F + 12R |
| PTO Speed(r/min) | 540/720 or 540/1000 |
| PTO Shaft | 8 bearings + 6mm × 16 bearings + 6mm optional |
| Brake | Wet disc brake |
| Hydraulics | (No description) |
| Lifting Force (at 610mm) kN | ≥8.9 (907.8kg) |
| 3-Point Hitch | Category 2 |
| Number of Valves | 2 pairs |
| Tractor Dimensions | (No description) |
| Drive Type | 4×4 |
| Length×Width×Height (mm) | 3845 × 1860 × 2730 |
| Wheelbase (mm) | 2110 |
| Minimum Ground Clearance (mm) | 350 |
| Minimum Operating Mass (with Cab) kg | 2800 |
| Wheel Track (F/R) mm | 1400/1400 |
| Tyres (F/R) | 8.3-24/14.9-30 |
| Optional Mass (F/R) kg | 45/96 |
| Cabin | Yes |
| Colour | Red, Blue, Green, Orange, Black, etc. |
| Options | Tyres (9.5-24/16.9-30, 9.5-24/14.9-30, 9.5-24/16.9-30, 9.5-24/16.9-30), ROPS, roll cage, hood, cab side windows, trailer air brakes, swinging drawbar, counterweight (45/R40kg), etc. |
