| Category | Item | Details |
| Engine | Manufacturer | Yanmar/Cummins |
| Model | 4-cylinder vertical water-cooled diesel engine |
| Torque | 107.7N·m |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 28L |
| Fuel Injection Method | Direct injection |
| Rated Power | 28.2kW(38.1HP)@2600rpm |
| Valve Type | Full overhead valve system |
| Cooling Method | Forced cooling |
| Cooler Cleaning (Optional) | Auto start + manual flushing (optional) |
| Cooler Seal | Standard |
| Allowable Tilt Angle | 60° in any direction (after engine optimization) |
| Hydraulic System | Hydraulic Pump | Piston pump |
| Drive Motor | Large torque motor (Poclain) |
| Track Motor | Swing motor (84P) |
| Mower Deck Motor | Swing motor (84P) |
| Independent Circuit for Mower Deck | Yes |
| Independent Drive Circuit | Yes |
| Hydraulic Oil Specification | 23F (40L within the system) |
| Hydraulic Tank Capacity | 750L |
| Hydraulic Pipe Upgrade | 80kg square type (after hydraulic system optimization) |
| Allowable Tilt Angle of System | 70° in any direction (after hydraulic system optimization) |
| Remote Control System | System Distance | Working radius ≤150m |
| Frequency | Frequency 433MHz |
| Battery | 2 built-in lithium batteries |
| Proportional Joystick | Extra charger, supports self-charging of the device |
| Engine Start/Stop | Remote control |
| Engine Speed | Remote control |
| Headlight | Remote control |
| Horn | Remote control |
| Safety | Steering Control | Remote control |
| Emergency Stop | One-button stop |
| Tilt Angle Protection | Alarm (horn + warning light) + auto stop |
| Headlight | LED |
| Signal Loss | Auto stop |
| Others | Hydraulic oil level/oil pressure abnormality + auto stop |
| Dimensions & Weight | Overall Width (with Mower Deck) | 1500mm |
| Overall Length (with Mower Deck) | 2900mm |
| Overall Height (with Mower Deck) | 1300mm |
| Net Weight | 1250kg |
| mowing platform | 200Kg |
| Performance | Supportable Slope | Hydraulic device tilt angle 55° (55°+device + mower deck + warning light; 55°=device tilt rate) |
| Stepless Speed Control (0 to 100%) | Construction speed: forward/backward 0-4Km/h; special reverse speed: 0-9Km/h |
| Brake | Remote control |
| Steering | Skid steering, engine tilt steering |
| Slope Travel Retraction | Yes |
| Constant Speed Cruise | Yes (one-button release) |
| Attachments + Mower Deck | Standard Attachment | Mower deck (Y-blade) |
| Hydraulic Flow of Attachment | 84L/min |
| Pressure | 250bar |
| Overload Pressure Cutoff | Yes |
| Tool | Tool Rotation Speed | 3000rpm |
| Tool Rotation Direction | Forward/reverse (stepless adjustable 0-100%) |
| Attachment Front Rake | Front/rear scraper plate |
| Rubber Belt Platform Control | Remote control |
| Rubber Belt (Standard) | Super wide rubber belt (supports 55° tilt working condition) |
| Y-blade | Shreds grass and wood (max diameter 30mm) |
| Tip Length | 1350mm |
| Tool Rotation Adjustment | 300mm |
| Mowing Height Adjustment (height adjustment wheel position) | 30mm-90mm (3 gears) (adjust mowing distance: mowing height 90mm) / 200mm-500mm |
| Front-end sliding table lifting | 200mm-500mm |
| Attachment Terrain Matching | Yes (matches terrain undulation ±10°) |
