| Key Specifications | |||
| Drive Wheels | 4WD | Engine Brand | YTO |
| Rated Power (HP) | 140HP | Application | Agricultural Tractor |
| Type | Wheel Tractor | Core Components | Gearbox, Engine, Others |
| Warranty Period | 1 Year | Drive Mode | Gear Transmission |
| Key Feature | Multi-functional | Mechanical Test Report | Not Available |
| Pre-shipment Video Inspection | Available | Origin | Shandong, China |
| Weight | 4680 | Brand | SHANDONG RONGXU/ODM |
| Diesel Engine | 6-Cylinder, Stage 2 Emission Standard (Mechanical) | Gear Shift | 16F + 8R |
| Tire | 12.4-24/16.9-34 | Tractor Dimensions | 4750*2100*3060 |
| Clutch | Dry Friction, Double-stage | Wheelbase | 2600mm |
| Minimum Ground Clearance (mm) | 420 | After-sales Service Provided | Free Spare Parts |
| After-sales Service | Online Support | Warranty Period | 1 Year |
| Category | Item | Details |
| Packaging & Shipping Info | Sales Unit | Single Product |
| Delivery Time | Quantity (sets) | 1-1 / >1 |
| US Eastern Time (days) | 30 / To be determined | |
| Customization Options | Custom Logo | MOQ: 1 sets |
| Custom Packaging | MOQ: 1 sets | |
| Graphic Customization | MOQ: 1 sets |
| Specification | Unit | Details |
| Tractor Model | / | RST1404 (TD Series) |
| Diesel Engine | / | 4-Cylinder, Stage 2 Emission (Mechanical) YTO Engine |
| Rated Power - Speed | kW/r/min | 103/2200～2300 |
| Transmission | / | - |
| Clutch | / | Dry Friction, Double-stage |
| Gear Shift | / | 16F + 8R |
| PTO Speed | r/min | 760/850, 540/1000 or 760/1000 |
| PTO Shaft | / | 8 Splines 540mm |
| Brakes | / | Wet Disc Brakes |
| Hydraulics | / | - |
| Lifting Capacity (at 610mm) | kN | 2.4×8 (2529.0 kg) |
| 3-Point Hitch | / | Category 2 |
| Hydraulic System Flow Rate | Pair | 3 |
| Tractor Size | / | 4 × 4 |
| Length × Width × Height | mm | 4750 × 2110 × 3060 |
| Wheelbase | mm | 2600 |
| Minimum Ground Clearance | mm | 420 |
| Total Mass/Weight (with Tank) | kg | 4680 |
| Tire Tread (F/R) | mm | 1620/1620 |
| Tire Size (F/R) | / | 12.4-24/16.9-34 |
| Ballast Weight (F/R) | kg | 300/180 |
| Cabin | / | Air-Conditioned |
| Color | / | Red, Blue, Green, Silver, Black, etc. |
| Options | / | - |
| Larger Tires | / | 13.6-24/16.9-38 |
| Smaller Tires | / | 12.4-24/16.9-34 |
| Trailer Air Brakes | / | Available |
| Stabilizer Bars | / | Available |
| Suspension Seat | / | Available |
| Power Take-off | / | Available |
| ROPS | / | Available |
| Ballast Weight (Front) | kg | 40 (per piece) |
| Ballast Weight (Rear) | kg | 0 |
