| Item | / | RST504-S |
| Diesel Engine |
|
|
| Type | / | 4-cylinder, Stage II Emission Standard (Mechanical) Yunnei Engine |
| Rated Power/Speed | kW/rpm | 36.8/2400 |
| Transmission |
|
|
| Clutch | / | Dryer, Single-stage |
| Gear Shift | / | 8F + 2R |
| PTO Speed | r/min | 540 |
| Brake | / | Dry Disc Brake |
| Hydraulics |
|
|
| Lifting Force (at 610mm) | kN | ≥8.9 (907.8kg) |
| 3-Point Hitch | / | Category 1 |
| Number of Hydraulic Valves | Pair | 1 |
| Tractor Dimensions |
|
|
| Drive Type | / | 4×4 |
| Length × Width × Height | mm | 2000×1345×2085 |
| Wheelbase | mm | 1553 |
| Minimum Ground Clearance | mm | 130 |
| Minimum Operating Mass (with ROPS) | kg | 1440 |
| Wheel Track (F/R) | mm | 920/960 |
| Tyre Size (F/R) | / | 6.0-12/9.5-24 |
| Ballast Weight (F/R) | kg | 25/40 |
| Weight | / | 1440 |
| Colour | / | Red, Blue, Green, Orange, Black, etc. |
| Trailer Air Brake | / | Available |
| Swinging Drawbar | / | Available |
| Hydraulic Valve | / | Available |
| Hydraulic Multi-Valve | Pair | 2 |
| Clutch & Gear Shift | / | Dual-stage, 8F + 8R |
| 2WD | / | Front Wheel Track 400-14 |
| Instruments | / | Fuel Gauge, Tachometer, Hour Meter |
