Weight | 1000kg |
Excavator bucket capacity | 0.025cbm/20kg |
Bucket width | 380mm |
Engine | B&S Gasoline engine/Kop |
Rated power | 10.1kw/7kw |
Displacement | 0.211L |
Compression stroke | 70x55 |
Displacement | 6.5kw/r |
Travel speed | 1.5km/h |
Overall dimensions (L×W×H) | 2900×900×2180mm |
Wheelbase | 910mm |
Total track length | 1200mm |
Main dimensions | - |
Overall dimensions (L×W×H) | 2900×900×2180mm |
Gauge | 910mm |
Track single-point clearance | 1200mm |
Platform ground clearance | 200mm |
Tail swing radius | 734 mm |
Chassis width | 906 mm |
Track width | 180 mm |
Track height | 132 mm |
Working range | - |
Digging depth | 1750 mm |
Vertical digging depth | 1350 mm |
Digging height | 2610 mm |
Dumping height | 1850 mm |
Digging radius | 3050 mm |
Swing radius | 1380 mm |
Dozer blade lifting height | 348 mm |
Dozer blade digging depth | 255 mm |
