Brand | ShanDongRongXu |
Bucket Capacity | 0.025cbm |
Hydraulic Cylinder Brand | Customer's Request |
Engine Brand | KOOP/Optional |
Place of Origin | Shandong, China |
Warranty Period | 1 Year |
Hydraulic Pump Brand | Customer's Request |
Hydraulic Valve Brand | Customer's Request |
Power (W) | 10.2kw/2500r/min |
Movement Type | Crawler Excavator |
Maximum Digging Height | 2610 mm |
Maximum Digging Depth | 1750 mm |
Machine Weight | 1200 kg |
Maximum Digging Radius | 1330 mm |
Rated Speed | 1.5 Km/h |
Unique Selling Point | Large Lifting Torque |
Mechanical Test Report | Available |
Factory Inspection Video | Available |
Core Components | PLC, Pressure Vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox, Others |
Weight | 1200kg |
Bucket Capacity | 0.025cbm/120kg |
Bucket Width | 380 mm |
Engine | Kubota D722 / 482 |
Cylinder Bore and Stroke | 3 Cylinders, Water-Cooled |
Rated Power | 10.2kw/2500r/min |
Displacement | 6.8ml/r |
Overall Dimensions (LxWxH) | 2775×930×2210 mm |
Wheelbase | 910 mm |
Track Total Length | 1230 mm |
