| Item | / | RST504 |
| Product Description Supplement | This tractor is 4WD, equipped with 4-cylinder Stage II Emission Standard (mechanical) Yunnei/Yanmar engine. TE8F + 2R gearbox, strong pressure, strong pressure lift, 1 pair of hydraulic valves, PTO shaft 6 splines * 35mm, speed 540/720 rpm, tires 7.50-20/12.4-28, weight 1450/96 kg | - |
| Tractor Model | / | RST504 |
| Diesel Engine |
|
|
| Type | / | 4-cylinder, Stage II Emission Standard (Mechanical) Yunnei/Yanmar Engine |
| Rated Power/Speed | kW/rpm | 36.8/2400 |
| Transmission |
|
|
| Clutch | / | Dryer, Single-stage |
| Gear Shift | / | 8F + 2R (Optional 8F + 8R) |
| PTO Speed | r/min | 540/720, 540/1000 |
| PTO Shaft | / | 6 Splines * 35mm |
| Brake | / | Dry Disc Brake |
| Hydraulics |
|
|
| Lifting Force (at 610mm) | kN | ≥8.9 (907.8kg) |
| 3-Point Hitch | / | Category 1 |
| Number of Hydraulic Valves | Pair | 1 |
| Tractor Dimensions |
|
|
| Drive Type | / | 4×4 |
| Length × Width × Height | mm | 3630×1550×2370 |
| Wheelbase | mm | 1860 |
| Minimum Ground Clearance | mm | 350 |
| Minimum Operating Mass (with ROPS) | kg | 1780 |
| Wheel Track (F/R) | mm | 1200/1200 |
| Tyre Size (F/R) | / | 7.50-16/11.2-28 |
| Ballast Weight (F/R) | kg | 45/96 |
| Cab | / | Optional |
| Colour | / | Red, Blue, Green, Orange, Black, etc. |
| Options |
|
|
| Other Tyres | / | 7.50-20/12.4-28, 7.50-16/12.4-24 |
| Semi-Solid Tyres | / | 7.50-16/11.2-28 |
| Paddy Field Tyres | / | 7.50-16/11.2-28, 7.50-20/12.4-28 |
| Trailer Air Brake | / | Available |
| Trailer Air Rod | / | Available |
| ROPS | / | Available |
| Cab | / | Cab Optional |
| Hydraulic Multi-Valve | Pair | 2 |
| Wheel Track (F/R) | mm | 1000/1000, 1100/1100, 1300/1300 |
| Steering Column | / | Adjustable Up/Down |
| Clutch & Gear Shift | / | Dual-stage, 8F + 8R |
| 2WD | / | Front Wheel Track 800-1600 |
| Instruments | / | Fuel Gauge, Tachometer, Hour Meter |
